MIXER AMPLIFIERS

Mobile PA Mixer Amplifiers

PA-200S

20 WATTS

12V DC Operation

  • 1 Mic & 1 Aux Input with individual volume control.
  • 12V Car Battery Operation.
  • Two Tone Siren (Wailing & Yelping) with volume control.
  • Recommended for use with Ahuja Mic MM-60M & Horn Speakers EHC-10/SUH-15.
  • Complies in size with the DIN standard.
  • Amplifier mounting bracket supplied alongwith.
  • Ideal for Police Vehicles, Crowd Control, Ambulances, Publicity Vans, Electioneering etc.
send enquiry
‹ ›

Power Output

30W Max., 20W RMS at 10% THD

Input Channels

1 × Mic 5.0mV/4.7kΩ, 1 × Aux 100mV/330kΩ

Frequency Response

250-10,000Hz ±3dB

Signal to Noise Ratio

60dB

Siren

Two Tones

Speaker Outputs

4Ω / 20W; 8Ω / 12W

Power Supply

12V DC (Car Battery)

Dimensions

W178 × H52 × D157 mm

Weight

1.10kg (with mounting clamp)
MIXER AMPLIFIERS : Mobile PA Mixer Amplifiers
PA-200S
20 WATTS
12V DC Operation
FEATURES :
  • 1 Mic & 1 Aux Input with individual volume control.
  • 12V Car Battery Operation.
  • Two Tone Siren (Wailing & Yelping) with volume control.
  • Recommended for use with Ahuja Mic MM-60M & Horn Speakers EHC-10/SUH-15.
  • Complies in size with the DIN standard.
  • Amplifier mounting bracket supplied alongwith.
  • Ideal for Police Vehicles, Crowd Control, Ambulances, Publicity Vans, Electioneering etc.
SPECIFICATIONS :

Power Output

30W Max., 20W RMS at 10% THD

Input Channels

1 × Mic 5.0mV/4.7kΩ, 1 × Aux 100mV/330kΩ

Frequency Response

250-10,000Hz ±3dB

Signal to Noise Ratio

60dB

Siren

Two Tones

Speaker Outputs

4Ω / 20W; 8Ω / 12W

Power Supply

12V DC (Car Battery)

Dimensions

W178 × H52 × D157 mm

Weight

1.10kg (with mounting clamp)
