MIXER AMPLIFIERS

250 WATTS

High Wattage PA Mixer Amplifier

6 Mic & 2 Aux Inputs.
Built-in digital effect processor for 2 Mic Inputs.
Preamplifier and Line Output for connecting to a Booster Amplifier and for recording the programme.
Line Input for connecting the output from any external mixer or permitting SSA-250®M to be used as a Booster Power Amplifier.
Resettable circuit breaker for protection against overload and short circuit. Instant transfer to DC power (Car Battery) if AC power fails.
Box Speaker/Driver Unit selector switch. Bass boost defeated at Driver Unit position for safer operation of driver units.

send enquiry

‹ ›

Power Output	300W Max., 250W RMS at 10% THD 220W RMS at 5% THD, 200W RMS at 2% THD
Output Regulation	≤ 2 dB, no load to full load at 1kHz
Input Channels	6×Mic 0.65mV/4.7kΩ, 2×Aux 100mV/470 kΩ, 1 × Line 1V/50kΩ
Delay System	Digital Signal Processing
Delay Range Setting	60-300ms
Frequency Response	50-15,000Hz ±3dB
Signal to Noise Ratio	60dB
Tone Controls	Bass: ±10dB at 100Hz, Treble: ±10dB at 10kHz
Outputs	Preamp 200mV/600Ω, Line 1V/1kΩ
Speaker Outputs	4Ω, 8Ω, 70V & 100V
Power Supply	AC: 220-240V 50/60Hz DC: 24V (2×12V Car Battery)
Power Consumption	AC: 460VA DC: 6A
Dimensions	W450 × H160 × D340 mm
Weight	15.70kg

Operation Manual

6050 KB
